Function description
<p>Light source brand:Japan Nichia<br>Light source power:<br>R:8000mw/638nm; <br>(5x6mm ;<1.0 mrad) <br>G:10000mw/525nm; <br>(4×6.5mm ;<1.0 mrad ) <br>B:12000mw/450nm; <br>(3×6.5mm ;<1.0 mrad)<br>Input voltage:110-240v;50/60Hz <br>Power: 570W <br>Modulation: Ang 100K/TTL <br>Control way:DMX/Auto/Sound/Master and slave <br>Brand of laser diode: Nichia,Mitsubishi <br>Life: 20000 hours <br>IP rate：IP65 <br>Operation temperature: -10°-40°<br>Product size：54*48*20.5cm<br>Net weight：26KG<br>Package size (Flight case): 68*56*38.5cm<br>Gross weight (Flight case): 40.6KG<br>Control mode: lLDA/Sound active/Auto/DMX512/Master-slave</p>
Parameters
Brand Name
VSHOW
Input Voltage
110-240v;50/60Hz
Power consumption
570W
Light source
R:8000mw/638nm; (5x6mm ;<1.0 mrad) G:10000mw/525nm; (4×6.5mm ;<1.0 mrad ) B:12000mw/450nm; (3×6.5mm ;<1.0 mrad)
Modulation mode
Ang 100K/TTL
Working temperature
-10°-40°
Net Weight
26KG
Package dimensions
68*56*38.5cm
G.W
40.6KG
IP
IP65
Fixture size
54*48*20.5cm
