Product Features:
1. All-in-One Three-in-One Lighting Effects: Integrating beam, pattern, and color-changing functions, a 450W high-power engine with 3-50° zoom allows a single unit to meet diverse stage lighting needs, achieving high efficiency and cost reduction.
2. Professional Color Control: Featuring linear CMY color mixing and CTO color temperature adjustment (2800K-8500K), coupled with a 7-color + white light color wheel and a high CRI of 90, ensuring accurate and natural color reproduction suitable for various professional scenarios.
3. Rich Dynamic Effects: Equipped with dual prisms (8+6 rows) that can be stacked and rotated, as well as pattern discs, fogging, strobe, and other effects, easily creating rich, dynamic visuals.
- Durable, Reliable, and Worry-Free: LED lifespan up to 20,000 hours, wide voltage design, overheat protection, fast heat dissipation, stable operation, and foldable light hook installation, suitable for long-term, high-intensity performances and rental scenarios.
Product Specification:
Input Voltage: 100-240V, 50/60Hz
Output Voltage: V1:48V:(LED driver)
V2:36V(Master board),
V2:12V(cooling fan+Display)
Power consumption: 480W
Power supply: 600W
Light source: 450W module LED engine (21-24V,8A)
LED expected service life: 20000 hours
LED temperature: 9000K
Diameter of optic lens: 148mm
Beam angle: 3-50°
Standard:70CRI
high :90CRI DMX
Channel: 29CH
Electric focusing system
Four dimming curves：Linear,Square law,Inverse squared law,S curve
Operate mode: DMX512, Auto, master/slave, RDM
0-100% 16bit linear smooth dimming
Multiple dimming frequency options
Multiple speed strobe effects
CMY color macro function
Linear CMY colour mixing
Linear CTO color temperature adjustment: 8500K-2800K
Color wheel: 1 color wheel, 7fixed colors plus white
Static gobo: 12 gobos plus 1 white circle
Rotation Gobo: 7 Gobo plus 1 white circle
Prism: Equipped with 8 prism, and 6 rows prism, the two prisms can be stacked and rotated in both
High brightness frost sheet: with smooth wash effect
Control panel: LCD Touch screen Overheating self-energy protection LED, extending LED life
X-axis rotation angle: 540°
Y-axis rotation angle: 270°
Three phase motor with SY Brand
XY axis magnetic coding positioning is more accurate
Power Outlet: Power Connector Input/Output
Signal Line: 3-pin or 5-pin signal line
Installation: folding clamp
Fixture size: 338*254*621mm
