Product Features:
1. 4-in-1 All-in-One Stage Light: Integrating four functions—beam, pattern, color, and cutting—this single light meets the needs of multiple scenarios, reducing equipment investment and improving on-site setup and usage efficiency.
2. 800W High-Brightness Optical System: Utilizing an 800W energy-saving LED light source paired with a high-quality lens, this light delivers uniform light spots, true-to-life color rendering, and a 3°-55° wide zoom range to meet lighting needs for different distances and scenarios.
3.Rich Creative Lighting Effects: Equipped with a linear CMY color mixing system, this light provides smooth and natural color transitions. Combined with pattern, cutting, prism, and fog effects, it easily achieves professional-grade stage visual creations.
4.Compact, Stable, and Professional: The lightweight and compact design makes installation and transportation more convenient. Intelligent temperature control ensures quiet and stable operation, and 16-bit dimming eliminates flicker, making it suitable for professional occasions such as performances, live broadcasts, and filming.
Product Specification:
Input Voltage: 100-240V, 50/60Hz
Output Voltage: V1:48V 18.75A(light source), V2:24V4.2A(a main board) Power consumption: 820W
Power supply: 1000W
Light source: 800W Module LED Engine
Lifetime:≥20,000Hours
Color temperature: 7500K
Linear CTO color temperature adjustment (3000K-7000K)
Standard color rendering index Ra ≥ 70
High color rendering index Ra ≥ 90
Diameter of optic lens: 120mm
Beam angle: 3°-55°
Linear CMY color mixing system
Color wheel: 1 color wheel, 5 fixed colors that can be rotated in both directions Fixed Gobo : 1 fixed gobo ,8 fixed gobo
Rotation Gobo: 1 rotating gobo , 7 Rotation Gobo, patterns can be replaced Animation gobo, imitating water patterns and flame effects, dynamic disc rotatable
Prism: 4 prisms that can be rotated in both directions (prism angle 14 °)
Two independent frost tablets (Mild and moderate) can be used in combination Cutting system: 4 grating to achieve fast and smooth cutting, each grating cutting direction and Angle can be independently controlled; The entire cutting module can be rotated 120°
0-100% 16bit smooth dimming(Four dimming modes)
Adjustable refresh frequency, HD camera shooting without flicker
More strobe effects, variable speed
DMX Channel: 27/29/36CH
Operate mode: DMX512, master/slave, RDM,Art-Net ,SACN Electronic autofocus
Outstanding strobe effect with variable speed
Control panel: LCD touch screen, touch buttons with backlight
Intelligent protection of overheat temperature
Built-in lithium battery, no power can also operate the menu Settings
X-axis rotation angle: 540°
Y-axis rotation angle: 270°
P/T: 16 bit precision scanning, no deviation
XY axis magnetic coding positioning is more accurate
Three phase motor with SY Brand
Signal socket: standard 3-pin XLR or 5-pin XLR socket and RJ45
Standard with 50MM folding fixture
Fixture size: 376x265x722.5mm
Net weight: 28KG
